Connecting the Outputs
Your FC‑404NET is provided with a 3-pin terminal block for each output channel. This
connector offers a balanced output to interface with the input of another device.
Connection methods for balanced and unbalanced outputs are identical as the methods for
inputs as referenced in Connecting the Inputs on page 6.
For any microphone that needs +48 volts of power, set the DIP-switch for that channel ON
(down).
