To connect the TP-590Rxr HDMI Line Receiver as shown in Figure 3:
• On the TP-590Txr transmitter:
1. Connect the HDMI source, (for example, a laptop) to the HDMI IN connector.
2. Connect an RS-232 serial controller to the RS-232 3-pin terminal block, (for
example, the serial port on a laptop) to control the projector.
3. Connect a stereo, analog audio source, (for example, the audio output of the
PC) to the Audio In 3.mm mini jack.
4. Connect the USB port on the laptop to the USB port on the front panel of the
TP-590Txr.
5. Connect an external IR emitter to the 3.5mm mini jack.
6. Connect the HDBT OUT RJ-45 connector to the HDBT IN RJ-45 connector
on the TP-590Rxr receiver.
7. Connect the supplied power adapter to the power socket and plug the
adapter into the mains electricity (not shown).
• On the TP-590Rxr receiver:
8. Connect the HDMI OUT connector to the HDMI acceptor, (for example, a
projector).
9. Connect the RS-232 3-pin terminal block to the device to be controlled, (for
example, the projector that is controlled by the PC which is connected to the
TP-590Txr).
10. Connect the IR 3.5mm mini jack to an IR sensor.
11. Connect the Audio Out 3.5mm mini jack to the audio acceptor, (for example,
amplified speakers).
12. If power is not supplied by the transmitter via PoE (see Section 3.2), connect
the supplied power adapter to the power socket and plug the adapter into
the mains electricity (not shown in Figure 3).
