Page #31 background imageLoading...
Page #31 background image
26
TP-590Rxr - Technical Specifications
9 Technical Specifications
INPUTS:
1 HDBT on a RJ-45 connector
OUTPUTS:
1 HDMI connector
1 Stereo analog audio on a 3.5mm mini jack
PORTS:
1 IR on a 3.5mm mini jack
1 USB on a USB connector
1 RS-232 on a 3-pin terminal block for the serial link
1 RS-232 on a 3-pin terminal block for control of the receiver
1 Ethernet on an RJ-45 connector for control of the receiver
BANDWIDTH:
Supports up to 10.2Gbps (3.4Gbps bandwidth per graphic
channel)
RS-232 BAUD
RATE:
115200
COMPLIANCE
WITH HDMI
STANDARD:
Supports HDMI and HDCP
USB STANDARD:
1.1 and 2.0
MAXIMUM AUDIO
LEVEL:
1Vrms
THD+N:
0.03%
SUPPORTED PC
WEB BROWSERS:
Windows 7 and higher:
Internet Explorer (32/64 bit) version 10
Firefox version 30
Chrome version 35
MAC:
Chrome version 35
Firefox version 30
Safari version 7
Note: Minimum browser window size 1024 x 768
ENCLOSURE
TYPE:
Aluminum
COOLING:
Convection, vents
OPERATING
TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE
TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
POWER
CONSUMPTION:
12V DC, 900mA
DIMENSIONS:
18.75cm x 11.5cm x 2.54cm (7.38" x 4.53" x 1.0") W, D, H
PRODUCT
WEIGHT:
0.5 kg (1.1lbs) approx.
SHIPPING
WEIGHT:
1.0kg (2.2lbs) approx.
VIBRATION:
ISTA 1A in carton (International Safe Transit Association)
SAFETY
REGULATORY
COMPLIANCE:
CE
UL
