TP-590Rxr - Protocol 3000
10 Protocol 3000
The HDMI Line Receiver can be operated using serial commands from a PC,
remote controller or touch screen using the Kramer Protocol 3000.
This section describes:
• Kramer Protocol 3000 syntax (see Section 10.1)
• Kramer Protocol 3000 commands (see Section 10.2)
10.1 Kramer Protocol 3000 Syntax
10.1.1 Host Message Format
Start
Address (optional)
Body
Delimiter
#
Device_id@
Message
CR
10.1.1.1 Simple Command
Command string with only one command without addressing:
Start
Body
Delimiter
#
Command SP Parameter_1,Parameter_2,…
CR
10.1.1.2 Command String
Formal syntax with commands concatenation and addressing:
Start
Address
Body
Delimiter
#
Device_id@
Command_1 Parameter1_1,Parameter1_2,…|
Command_2 Parameter2_1,Parameter2_2,…|
Command_3
Parameter3_1,Parameter3_2,…|…
CR
10.1.2 Device Message Format
Start
Address (optional)
Body
Delimiter
~
Device_id@
Message
CR LF
