Kramer TP-590TXR User Manual

8
TP-590Rxr - Connecting the TP-590Rxr HDMI Line Receiver
5 Connecting the TP-590Rxr HDMI Line Receiver
Always switch off the power to each device before connecting it to
your TP-590Rxr. After connecting your TP-590Rxr, connect the
power to each of them and then switch on the power to each
device.
You can use the TP-590Rxr HDMI Line Receiver and a compatible transmitter,
(for example, the TP-590Txr HDMI Line Transmitter) to configure an HDMI
transmitter/receiver system, as shown in the example in Figure 3.
Figure 3: Connecting the TP-590Rxr HDMI Line Receiver

Kramer TP-590TXR Specifications

General

Brand	Kramer
Model	TP-590TXR
Category	Transmitter
Language	English
