VM-214DT – Operating the VM-214DT Remotely Using the Web Pages
20
Figure 19: RS-232 Switching Example
IR Switching Example
In the example configuration shown in Figure 20 IR data is routed from the IR sensor on the
front panel and the IR 3.5mm mini jack on the rear panel to all outputs, (HDBT Output 2, 3, 4,
and 5).
Figure 20: IR Switching Example

Kramer VM-214DT Specifications

General

Brand	Kramer
Model	VM-214DT
Category	Switch
Language	English
