VP-551X – Operating and Controlling VP-551X
13
Setting Output Parameters
To set the output parameters:
1. On the front panel press MENU. The menu appears.
2. Click Output and define the output parameters according to the information in the
following table:
Menu Item
Function
Size
Set the size of the image: Full, Overscan, Under 1, Under 2, Letterbox, Panscan, Best fit
(default), Follow In.
Bypass mode
(4Kin->4Kout)
Yes (Bypass): Select for 4K HDMI signals to bypass the scaler (no video processing).
No (Scaler): Select to always scale the HDMI signals.
Resolution
Select the output resolution (default, NATIVE HDMI):
Appears as
Output Resolution
Appears as
Output Resolution
640x480 60
640x480 @60Hz
800x600 60
800x600 @60Hz
1024x768 60
1024x768 @60Hz
1280x768 60
1280x768 @60Hz
1280x800 60
1280x800 @60Hz
1280x1024 60
1280x1024 @60Hz
1360x768 60
1360x768 @60Hz
1400x1050 60
1400x1050 @60Hz
1440x900 60
1440x900 @60Hz
1600x1200 60
1600x1200 @60Hz
1680x1050 60
1680x1050 @60Hz
1920x1200 60 RB
1920x1200 @60Hz RB
2560x1600 60 RB
2560x1600 @60Hz RB
1920x1080 60
1920x1080 @60Hz
1280x720 60
1280x720 @60Hz
2560x1440 60 RB
2560x1440 @60Hz RB
720x480P 60
720x480P @60Hz
720x576P 50
720x576P @50Hz
1280x720P 50
1280x720P @50Hz
1280x720P 60
1280x720P @60Hz
1920x1080P 24
1920x1080P @24Hz
1920x1080P 25
1920x1080P @25Hz
1920x1080P 30
1920x1080P @30Hz
1920x1080P 50
1920x1080P @50Hz
1920x1080P 60
1920x1080P @60Hz
2560x1080P 50
2560x1080P @50Hz
2560x1080P 60
2560x1080P @60Hz
3840x2160P 24
3840x2160P @24Hz
3840x2160P 25
3840x2160P @25Hz
3840x2160P 30
3840x2160P @30Hz
3840x2160P 50(420)
4k2k @50Hz (4:2:0)
3840x2160P 60(420)
4k2k @60Hz (4:2:0)
For HDMI only
3840x2160P 50
3840x2160P @50Hz
3840x2160P 60
3840x2160P @60Hz
