The first is the ‘welcome’ display shown above indicating the model of the unit.
Moving to the next menu item displays the firmware information screen (the
numbers on your unit will be different to those shown). The SW number refers to
the version of firmware loaded into the unit, this can be upgraded from our website.
The PT and BT numbers refer to Hardware version information and are of interest
to the Technical Support Group should you ever need assistance.
At the end of all Group Menus will be an ‘Exit’ item. Simply select this to exit the
existing menu structure and return to the previous one in the hierarchy.
8.2 Group Names and Descriptions
Menu Group Name Group Description
Adjust outputs Controls output parameters
Adjust windows Controls characteristics of the scaled window
Adjust keyers* Controls the keying ability of the unit
Adjust sources Controls signal source input parameters
Adjust resolutions Controls unit’s input/output resolution table (hidden by
default - only visible when advanced menus are switched
on)
System Controls global system parameters for the unit
*Note that not all units have this menu item
8.3 Items Associated with the Adjust outputs group
This menu group allows adjustments to be made that specifically affect the output
of the unit, including output resolution and locking/overlaying onto a computer or
video source.
This menu item allows the lock mode to be selected and the lock source to be
defined. The top line of the display shows the current detected resolution of the
(Model number)
Kramer Electronics
kramerelectronics.com
SW: 65. PT: 12, BT: 13
800 x 600 60Hz
