6-2 Issue 03, 04/2005 Krautkramer DynaPOCKET
Housing
Setup Miniaturized processor-controlled rebound hardness tester.
Impact device with integrated electronics.
Battery compartment 2 AAA cells, lid with snap-in lock
Dimensions (dia. × L) approx. 38 × 170 mm / 1.5 x 6.7 in
Weight approx. 200 g / 0.4 lb.
Impact energy approx. 12 Nmm
Impact device Dyna D (for all materials enabling testing)
Switch-on press of a key
Switch-off automatic switch-off after approx. 1 min (single measurement mode) /
3 min (measurement set with average display)
Display and keypad
Display LCD, display of the hardness value via 4 seven-segments, status indicators
Keypad Membrane keypad with 2 click keys
Technical data
