Pre-Operation
Review this section before you begin. Ensure you have all tools/materials on hand
and compare the package with the items listed in the Hardware Included and Product
Description sections. If any item appears missing or lost, do not use this product.
Contact Technical Support or return product to place of purchase.
Product Description
A
B
C
D
K
F
H
I
J
G
L
M
E
Part Description Part Description
A Base H Stop collar
B Drill-guide socket I Hex wrench
C Toggle clamp J Driver bit
D Clamp pad K Pocket-screw sample pack
E Standard drill guide L Pocket-hole plug sample pack
F Drill-guide locking pin M Vacuum port
G Step bit
