Kreg KHI-XLPULL - Pre-Assembly and Components; Required Tools and Materials; Included Jig Components

3
Pre-Assembly
Review this section before you begin. Ensure you have all tools/materials on hand and compare
the package with the items listed in the Tools Included and Product Description sections. If any
item appears missing or lost, do not use this product. Contact Customer Experience or return
product to place of purchase.
Recommended Tools/Materials (NotIncluded)
Measuring Tape 3/16 in. Drill Bit Pencil Center Punch Backer Board
Tools Included
5/64 in. Hex Wrench
Product Description
A
C
B
E
F
E
D
H
G
G
G
Part Description
A Depth Bar
B Cross Bar
C Alignment Stop
D End Stop
E Adjustable Drill Guides
F Fixed Center Drill Guide
G Thumb Screws
H Socket Head Cap Screws
