Pre-Assembly
Kreg strongly recommends the use of Kreg Flush-Trim Bit - 1/4" Shank (PRS250), or the Kreg
Flush-Trim Bit - 1/2" Shank (PRS500) with this product. See Kreg distributors or kregtool.com for
purchase. Have your trim router, router, or router table nearby and follow the bit installation to that
power tool. This information can be found in the owner’s manual for the power tool.
Review this section before you begin. Ensure you have all tools/materials that were in the
package on hand and compare them with the items listed in the Hardware Included and Product
Description sections. If any item is missing, do not use this product. Contact customer experience
or return the product to the place of purchase.
Product Description
A B
C
D
E
F
Part Description Qty. Part Description Qty.
A Base plate 1 D Prole case 1
B Handle (pre-installed) 1 E Chamfer prole templates 3
C Edge stop posts (pre-installed) 4 F Radius prole templates 5
