Krober O2 - Fan Installation

Kröber O2
Service work
40
3.5.1.2 Fan installation
1. Install the fan so that the fan
wheel or the airflow arrow points
towards the sheet metal.
2. Tighten the four fastening
screws hand-tight.
3. Press the fan panel back evenly
into the grooves as far as it will
go. Make sure that the silicone
profiles are guided along.
4. If necessary, readjust the
position of the compressor lines.
