1. Carefully insert the functional unit
into the shaft and push it through
to the end. When doing so, push
any hoses present from the
interior to the side to allow a free
path.
2. Place both pressure hoses on the
connection pieces one after the
other using pliers and push them
through as far as they will go.
Apply only moderate force so that
the hoses are not damaged by
the pliers.
NOTE!
The upper hose comes from the
cooling coil, the lower hose
connects the discharge silencer
located in the compressor
compartment.
