6 TECHNICAL DATA
44
OPTIMASS 7000
www.krohne.com 10/2015 - 4001016303 - MA OPTIMASS 7000 R03 en
Measuring tube in Titanium (T), Stainless Steel (S) or Hastelloy
®
(H)
Dimensions [mm]
T/S 06 T/S/H 10 T/S/H 15 T/S/H 25 T/S/H 40 T/S/H 50 T/S/H 80
A 102 115 170 220 274
B 1 420 ±2 510 ±2 548 ±2 700 ±2 925 ±2 1101 ±2 1460 ±4
B 2 428 ±2 518 ±2 556 ±2 708 ±2 933 ±2 1109 ±2 1468 ±4
C1 (compact) 311 318 345 370 397
C2 (remote) 231 ±2 237 ±2 265 ±2 290 ±2 317 ±4
D 160
E 60
F 123.5
G 137
H 98.5
1 all pressure ratings up to 600 lbs and all DIN flanges with standard raised faces.
2 ASME flange 600 lbs and all DIN flanges with raised face types: C; D; E and F.
Dimensions [inches]
T/S 06 T/S/H 10 T/S/H 15 T/S/H 25 T/S/H 40 T/S/H 50 T/S/H 80
A 4 4.5 6.7 8.7 10.8
B 1 16.5± 0.08 20 ±0.08 21.6 ±0.08 27.5 ±0.08 36.4 ±0.08 43.3 ±0.08 57.5 ±0.16
B 2 16.8 ±0.08 20.4±0.08 21.9 ±0.08 27 ±0.08 36.7±0.08 43.3 ±0.08 57.8 ±0.16
C1 (compact) 12.2 12.5 13.6 14.6 15.6
C2 (remote) 9 ±0.08 9.3 ±0.08 10.4 ±0.08 11.4 ±0.08 12.5 ±0.16
D 6.3
E 2.4
F 4.9
G 5.4
H 3.9
1 all pressure ratings up to 600 lbs and all DIN flanges with standard raised faces.
2 ASME flange 600 lbs and all DIN flanges with raised face types: C; D; E and F.
