KROHNE OPTIMASS 7000 - Page 45

TECHNICAL DATA 6
45
OPTIMASS 7000
www.krohne.com10/2015 - 4001016303 - MA OPTIMASS 7000 R03 en
Measuring tube in Tantalum (A)
Dimensions [mm]
A 10 A 15 A 25 A 40 A 50
A 102 102 115 170 220
B (standard flange) 557 ±2 633 ±2 800 ±2 1075 ±2 1281 ±2
C1 (compact) 311 311 318 345 370
C2 (remote) 231 ±2 231 ±2 237 ±2 265 ±2 290 ±2
D 160
E 60
F 123.5
G 137
H 98.5
Dimensions [inches]
A 10 A 15 A 25 A 40 A 50
A 4 4 4.5 6.7 8.7
B (standard flange) 21.9 ±0.08 21.6 ±0.08 27.5 ±0.08 36.4 ±0.08 43.3 ±0.08
C1 (compact) 12.2 12.2 12.5 13.6 14.6
C2 (remote) 9 ±0.08 9 ±0.08 9.3 ±0.08 10.4 ±0.08 11.4 ±0.08
D 6.3
E 2.4
F 4.9
G 5.4
H 3.9
