TECHNICAL DATA 6

OPTIMASS 7000

www.krohne.com10/2015 - 4001016303 - MA OPTIMASS 7000 R03 en

Dimension B [inches]

T/S 06 T/S 10 T/S 15 T/S 25 T/S 40 T/S 50 T/S 80

Tri-clover

Tri-cloverTri-clover

Tri-clover

½" 18.9 ±0.08 22 ±0.08 - - - - -

¾" - - 23.5 ±0.08 - - - -

1½" - - - 32.1 ±0.08 - - -

2" - - - - 41 ±0.08 - -

3" - - - - - 51.4 ±0.08 -

4" - - - - - - 49.5 ±0.08

Tri-clamp DIN 32676

Tri-clamp DIN 32676Tri-clamp DIN 32676

Tri-clamp DIN 32676

DN10 19 ±0.08 22.2 ±0.08 - - - - -

DN15 - - 23.7 ±0.08 - - - -

DN25 - - - 30 ±0.08 - - -

DN40 - - - - 38.8 ±0.08 - -

DN50 - - - - - 46 ±0.08 -

DN80 - - - - - - 62.4 ±0.08

Tri-clamp ISO 2852

Tri-clamp ISO 2852Tri-clamp ISO 2852

Tri-clamp ISO 2852

1½" - - - 32.2 ±0.08 - - -

2" - - - - 41.1 ±0.08 - -

3" - - - - - 51.4 ±0.08 -

4" - - - - - - 60.1 ±0.08

DIN 11864-2 form A

DIN 11864-2 form ADIN 11864-2 form A

DIN 11864-2 form A

DN10 - 20.8 ±0.08 - - - - -

DN15 - - 22.3 ±0.08 - - - -

DN25 - - - 28.3 ±0.08 - - -

DN40 - - - - 37.3 ±0.08 - -

DN50 - - - - - 44.3 ±0.08 -

DN80 - - - - - - 60.5 ±0.08
