20
OPTIMASS 1300C T6 with stainless steel converter housing & without heating
jacket / insulation
Ambient Temp.
T
amb
°C
Max. medium
temp. T
m
°C
Temperature Class
Max. Surface
Temp. °C
40
45 T6 T80
60 T5 T95
100 T4 T130
130 T3 – T1 T155
50
60 T5 T95
100 T4 T130
130 T3 - T1 T160
55 55 T4 - T1 T95
OPTIMASS 1300 T6 with stainless steel converter housing and heating jacket / insulation
Ambient Temp.
T
amb
°C
Max. medium
temp. T
m
°C
Temperature Class
Max. Surface
Temp. °C
40
45 T6 T80
60 T5 T95
95 T4 T130
120 T3 – T1 T155
50 60 T5 T95
75 T4 - T1 T110
55 55 T4 - T1 T130
* Only for equipment configurations according to the table in section 2.2
The cable supplied by KROHNE is designed for a continuous working temperature of up to
105°C. Alternative cabling must be a heat-resistant type with a minimum continuous working
temperature of 80°C.
