14
Power Supply Circuit Data Circuit
Ui = 16.5V Ui = 11.8V
Ii = 340mA Ii = 40mA
Pi = 1.3W Pi = 120mW
Ci = 35nF Ci = 35nF
Li = 10uH Li = 10uH
For non-Ex i signal outputs
Ex d connection compartment Ex e connection compartment
II 1/2 G Ex d [ib] IIC T4....T1 Ga/Gb II 1/2 G Ex de [ib] IIC T4....T1 Ga/Gb
II 2 D Ex t IIIC T265°C Db II 2 D Ex t IIIC T265°C Db
For Ex i signal outputs
Ex d connection compartment Ex e connection compartment
II 1/2(1) G Ex d [ia/ib] IIC T4....T1 Ga/Gb II 1/2(1) G Ex de [ia/ib] IIC T4....T1 Ga/Gb
II 2(1) D Ex t [ia Da] IIIC T265°C Db II 2(1) D Ex t [ia Da] IIIC T265°C Db
1.10 OPTIMASS 8000k / 8010kC / 8300kC
The OPTIMASS 8000k / 8010kC mass flow sensors / mass flow meters are designed with
intrinsically safe protection type. The marking for the OPTIMASS 8000k / 8010kC is as follows:
II 1/2 G Ex ib IIC T4...T1 Ga/Gb
II 2 D Ex ib IIIC T210°C Db
The input connections to the OPTIMASS 8010kC / 8010kC for use with associated apparatus
have the following maximum values:
The marking for the compact OPTIMASS 8300kC is as follows::
AD OPTIMASS 300_010 Haz Areas Rev 01.qxp 05/03/2014 13:24 Page 14
