Krups Precision range XP80 - Descaling the Machine

98
ENGLISH
b) The Coee Grinder
Regularly cleaning the grinder and the grinder outlet with the cleaning brush is important to
ensure long life of your machine.
IMPORTANT: When cleaning the grinder, please make sure there are no beans in the bean hopper.
To remove the last beans in the grinder, press the START/STOP GRIND button (19), wait for the last
coee ground to go out and press again the button to stop.
WARNING: Please unplug the machine before cleaning the grinder (4)
1. Rotate the bean box anti-clockwise to remove the bean box, by aligning the following arrow
marked on the bean hopper with the orange index on the machine (12).
2. Turn the internal grinding wheel anti-clockwise and take it out (41). Use the cleaning brush
to clean the grinding wheel and remove the ground coee in the gears (43). Please note that
the grinding wheel cannot be directly rinsed with water (only with the brush).
3. Use the cleaning brush to clean the grinding chamber and the ground coee channel (44).
4. Do not install the grinding wheel at this time, re-install the empty bean hopper (46).
5. Plug the machine, press the power button and press the START/STOP GRIND button (19), let
the grinder run to sweep out the coee ground residue in the grinding chamber. (If coee
ground inside is not removed completely, please repeat step 3 and 4).
6. Turn o and unplug the machine.
7. Remove the bean hopper anti-clockwise (4).
8. Install the grinding wheel securely in position (45).
9. Install the bean hopper back on the machine (46).
Cleaning is completed.
c) The brewing head
Daily cleaning
After your coee extraction, clean your coee brewing head with a ush: remove your portalter,
remain on coee recipes on the ‘Recipes Dial’ and press the START/STOP BREW button (8). Press
again after a few seconds to stop.
You can also clean the brewing head with brush after each extraction.
Regular cleaning:
Please rinse the coee brewing head regularly as following steps:
1. Insert 2-cup single wall lter into the portalter (9).
2. Put the blind sieve in the lter so that the holes of the lter are hidden (47).
3. Insert the portalter into the brewing head (25).
4. Select Espresso, then press START/STOP BREW (8) button to start rinsing process (about 30
seconds), rinsed water goes directly into the drip tray.
5. Rinsing process stops automatically. Remove the portalter and the blind sieve. Empty the
portalter if some hot water remains.
6. Empty the drip tray when it is full (48).
7. START/STOP BREW indicator becomes orange x, press the START/STOP BREW button to
return normal (8).
d) The water circuit
Please clean the coee and steam water circuit once every 3 months:
1. Remove and empty the drip tray (48), then reposition it in the machine.
2. Insert 2-cup lter into the portalter (9).
3. Put the blind sieve in the lter so that the holes of the lter are hidden.
4. Place one KRUPS cleaning tablet* on the blind sieve (50).
5. Insert the portalter into the brewing head (25).
6. Select CALC on the RECIPES AND CLEANING DIAL (51).
DESCALING THE MACHINE
When the CALC indicator red light is on, you need to descale your machine. You can start descaling
at any time. Make sure the portalter is not inserted to the machine.
1. Remove and empty the drip tray (48), then reposition it in the machine.
2. Empty the water tank (54). Remove the lter if present (you can re-insert it at the end of the
descaling process) (55).
3. Put the KRUPS Descaler* into the water tank (56) and add 500ml / 17.5 oz of water. Put a
container (1L / 34 oz) on the drip tray under the coee outlet, hot water outlet and under the
steam wand (6).
4. Turn the RECIPES AND CLEANING dial to CALC.
5. Press the START/STOP BREW button to start descaling process (8).
6. Water comes out from each outlet (Brewing head for 2 min 30 sec, Hot water outlet for 2 min
30 sec, Steam outlet for 2 min 30 sec). This cycle repeats automatically one more time.
7. START/STOP BREW button indicator is blinking white. The Descaling is nished now, proceed
to rinsing.
8. Empty the container (57). Remove the water tank, empty out any residual descaler solution
(54), rinse under running water and ll with fresh water (1L/34 oz). Put the water tank and
the container back on the machine.
9. Press START/STOP BREW button (8).
10. Water comes out from each outlet (Brewing head for 30 sec, Hot water outlet for 30 sec,
Steam outlet for 30 sec). This cycle repeats automatically one more time.
11. Once nished rinsing process, START/STOP BREW button light and Power button light
become xed white.
12. Empty the container (57), remove the water tank, ll with fresh water and reposition it in the
machine. If present, re-set water lter.
13. Turn the RECIPES AND CLEANING dial to one of the beverages.
The machine is now ready for use.
To exit DESCALING MODE halfway, press the POWER button (9). This does not clear the descaling
alert.
Note: *The KRUPS Descaler can be purchased on the Krups ocial website or other retailers.
7. Press START/STOP BREW button (8) and hold down for 3 seconds to start cleaning process.
The water used for cleaning goes directly into the drip tray. It lasts about 3 minutes.
8. Remove the portalter. Check if the tablet is dissolved completely. If not, please repeat the
point 5, 6 and 7.
Note: *The KRUPS Cleaning Tablet XS3000 can be purchased on the Krups ocial website or other
retailers.
