KSB AmaControl INT 600 DM User Manual

1 Supplementary Operating Manual
45 of 48
AmaControl
2301.83/04-EN
Feature Characteristic Value
Activation of remote
reset
Quantity Max. 3 activations within 1day
Relay Contact AC 240V 2.5A C300 at least AC/
DC 24V 20mA
Mechanical service life Approx. 1 million switching
cycles
Modbus Protocol Modbus RTU (2-wire interface/
W2-Modbus)
Start addresses Adjustable 1
1)
, 17, 33, 49
Number of assigned
addresses
16
Suitable power cable Cable LiYCY (TP) 2x2x0.25
Safety Electrically isolated
Specification Application protocol
specification of the Modbus-IDA
Interface RS 485
Baud rate 9600, 19200
1)
, 38400 or 57600,
adjustable
Parity Even, odd, or no
1)
, adjustable
Stop bit 1 or 2
1)
Enclosure to EN60529 IP 20
Connection type Power supply Screw terminals max. 2.5mm
2
Round
DP interfaces 3-pin connector
Modbus interface Screw terminals max. 2.5mm
2
Housing material PC
Mounting Can be snap-mounted on 35mm
standard rail to EN60715
Dimensions (ðSection1.5.1.2,Page46)
Weight Approx. 200g
Test specifications DINEN61000-6-2,
DINEN61000-6-3,
DINEN61010-1 overvoltage
categoryII -Pollution degree2
1
Factory setting

KSB AmaControl INT 600 DM Specifications

General

Brand	KSB
Model	AmaControl INT 600 DM
Category	Gateway
Language	English
