1 Supplementary Operating Manual
44 of 48
AmaControl
2301.83/04-EN
No. Error text Type Description
135 Frequency inverter Warning Excessive percentage deviation of one phase from the mean
value of the 3 phases (asymmetry).
136 Temperature 3 Warning Permissible warning value for the temperature at the
temperature input has been exceeded.
141 Temperature 3, warning Warning Temperature 3, warning
142 Underload Warning Warning Insufficient effective power was detected at the motor.
143 Overload Warning Warning Excessive effective power was detected at the motor.
236 Monitoring
Motor temperature PTC
Message One of the two PTC tripping paths has not tripped.
237 Communication error Message Communication error between sensor unit and analysing
unit. Data could not be exchanged or could not be
exchanged completely. Monitoring functions are not
affected by this.
238 Self-monitoring, PTC analog
channel
Message Self-monitoring, PTC analog channel
239 Memory failure Message An error occurred while saving the statistics values. The
statistics values affected have been reset.
240 Relay 1 bridged Message Relay 1 bridged
241 Reset external Message Reset external
242 Reset button Message Reset button
243 HardFaultHandler Message HardFaultHandler
244 Emergency operation Message Emergency mode activated; monitoring functions restricted
246 Operation despite shutdown Message The motor is still in operation although the protective
device has tripped.
Possible causes: alarm relay not connected or motor
protection defective.
247 Service Message Service interval has expired, carry out maintenance.
248 INTspection Memory
storage was triggered
Message INTspection memory storage has been triggered.
249 Parameterisation via DP Message Parameterisation by means of DP successfully completed.
251 Power failure / shutdown Message Power failure / shutdown detected. Events after this entry
deviate by the duration of the power interruption until the
time has been resynchronised.
252 Real-time clock synchronisation Message Real-time clock has been set.
253 Reset via Modbus Message Reset via Modbus has been performed after the protection
device has been parameterised or switched off.
254 Reset via switching input Message Reset has been performed via switching input.
255 Power reset Message If several power resets occur one after the other, only the
first is entered in the event list. Time stamp may be offset
from this point onwards.
1.5 Related Documents
1.5.1 Technical data of INT 600 DM Gateway
Table19: Technical data of the display unit
Feature Characteristic Value
Power supply AC 50/60Hz 115-240V
(UL115-230V) ±10 % 2VA
Permissible ambient temperature -30...+70°C
Activation of remote
reset
Pulse duration after
activation
5s
Frequency Once every 30min
