KSB AmaControl INT 600 DM - Application of INT 600 DM Gateway

1 Supplementary Operating Manual
5 of 48
AmaControl
2301.83/04-EN
1.2.2 Application of INT 600 DM Gateway
DANGER
Incorrect electrical installation
Risk of fatal injury due to electric shock!
▷ Always have the electrical connections installed by specialist personnel.
▷ Observe the technical specifications of the local and national energy supply
companies.
DANGER
Electric shock
▷ Connected sensors and connection cables outed out of the control cabinet must
have at least basic insulation.
NOTE
Short circuit
▷ Only KSB AmaControl devices may be connected to the DP interface.
The diagnostic system can output data recorded by AmaControl via the DP interface.
The operating status of the pump can thus be evaluated in the actual application.
Incidents can be responded to immediately.
The INT 600 DM Gateway reads in the DP interface. It then outputs the data via an
RS485 interface (Modbus RTU protocol).
Type series Modbus interface DP interface via INT 600
DM Gateway
AmaControl 3 - ✘
AmaControl L - ✘
AmaControl 4 ✘ ✘
