1 Supplementary Operating Manual
30 of 48
AmaControl
2301.83/04-EN
1.4.3 Modbus protocol, AmaControl 4 (DP interface INT 600 DM Gateway)
Parameters can be read with function code 4 (read input register).
NOTE
AmaControl 4 has a separate Modbus RTU interface (ðSection1.4.2,Page20) .
Alternatively, however, AmaControl 4 can also be read out using the INT 600 DM
Gateway.
Table15: Modbus Protocol, AmaControl 4
Start End Data type Description
10752 10752 High byte: visual ID Low byte: reserved u 16bit
10753 10753 High (12 bit): article main number Low (4-bit): reserved u 16bit
10754 10755 Consecutive serial number within article number, low word first u 32bit
10758 10758 Fault message
Bit 0: 0 = no fault, 1 = at least one fault currently present
u 16bit
10759 10759 Operating status
Bit 0 – motor status: 1 = motor running
Bit 6 – alarm relay
Bit 7 – warning relay
Bit 8 – reset input
Bit 9 – reset key
Bit10 – analog PTC
Bit11 – analog Bim {1 = active}
u 16bit
10766 10766 Software revision
High byte: major software revision number Low byte: minor software
revision number, displayed: major. minor (e.g. 1.02)
u 16bit
10767 10767 Function variant
0 = engineering sample
1-9 = variants
u 16bit
10770 10770 Article number variants
If value < 10000
"S" [value]
If value < 10000
"P" [value - 10000]
u 16bit
10771 10771 Voltage key 13=24VDC 20=24VAC/DC 22=115-230V AC 31=24VAC
41=115VAC 52=230VAC
u 16bit
10772 10773 Total number of fault trips Low word first u 32bit
10774 10775 Total number of pump starts Low word first u 32bit
10776 10776 Number of seconds of the current hour (internal time) 0 – 3599seconds u 16bit
10777 10777 Remaining delay period
Estimated time before the motor can be re-started
0..65,533 seconds
65,535 = interlocked tripping
65,534 = time undefined
u 16bit
10778 10779 Time stamp
Seconds elapsed since 01/01/1970 00:00:00,
POSIX format
u 32bit
10780 10781 Time stamp of last switching operation as per operating routine Seconds
from 01/01/1970 00:00:00, POSIX format
u 32bit
10788 10788 Number of hours of the current day (internal time) 0 - 23h u 16bit
