5.4.2.1 Material variant C2 (Noridur)
Table 10: Material variant C
2
(Noridur): Permissible forces and moments at the pump nozzles
8)
Pump size Nozzle
diameter
Forces Moments
Suction nozzle Discharge nozzle Suction nozzle Discharge nozzle
SS DS F
x
[N]
F
y
[N]
F
z
[N]
F
res
[N]
F
x
[N]
F
yTens
+
[N]
F
yPress
[N]
F
z
[N]
F
res
[N]
M
x
[Nm]
M
y
[Nm]
M
z
[Nm]
M
x
[Nm]
M
y
[Nm]
M
z
[Nm]
40-250 65 40 3145 2065 2515 3235 1527 990 1975 1255 1975 2065 1525 1080 990 810 540
40-315 80 40 3860 2515 3055 3950 2605 1975 1345
50-200 65 50 3145 2065 2515 3235 1527 990 1975 1255 1975 2065 1525 1080 1255 990 630
50-400 80 50 3860 2515 3055 3950 1975 1255 2425 1615 2515 2605 1975 1345
65-200
65-315
65-400
80
80
80
65
65
65
3860 2515 3055 3950 2515 1615 3145 2065 3235 2605 1975 1345 2065 1525 1080
80-250
80-315
80-400
100
100
100
80
80
80
4850 3145 3860 4940 3055 1975 3860 2515 3950 3595 2695 1795 2605 1975 1345
80-500 125 80 6645 4310 5300 6825 4940 3770 2515
100-250
100-315
100-400
125
125
125
100
100
100
6645 4310 5300 6825 3860 2425 4850 3145 5030 4940 3770 2515 3595 2695 1795
125-315
125-400
125-500
150
150
150
125
125
125
8445 5570 6735 8710 5300 3325 6645 4310 6825 6200 4760 3145 4940 3770 2515
150-315
150-400
150
150
150
150
8445 5570 6735 8710 6735 4220 8445 5570 8710 6200 4760 3145 6200 4760 3145
200-320
200-400
200-500
200
200
200
200
200
200
13205 8445 10240 13295 10240 6380 13205 8445 13295 9520 6915 4760 9520 6915 4760
250-315
250-400
250-500
250-630
250
250
250
250
250
250
250
250
17965 12035 14370 18770 14370 8980 17965 12035 18770 13470 10240 6555 13470 10240 6555
300-400
300-500
300
300
300
300
21555 14370 17965 22995 17965 11045 21555 14370 22995 16435 12395 8085 16435 12395 8085
350-400
350-500
350-630
350
350
350
350
350
350
23980 15630 19220 24790 19220 12035 23980 15630 24790 17155 12845 8445 17155 12845 8445
8)
For temperatures >20 °C: Adjust the values using the temperature correction coefficients (see previous page).
