Material v a r i ant C
2
:
Temperat u r e - dependent cor r e c t ion coefficie n t s
For material variant C2 at temperatures >20 °C reduce the values indicated in (=>
table 10, page 27) as per the following diagram:
0.3
0.4
0.6
0.7
0.8
0.9
1.0
0 50 100 150 200 250 300
C
2
k=f(t)
Korrekturfaktor
Fig. 12: Correction coefficient for material variant C
2
:
Calculation of forces and moments if t > 20 °C
Reduction formula: k (t) x forces/moments in the table
Example:
▪ Material = C2
▪ t = 100°C
▪ k = 0.825 (multiplication of data in table by 0.82)
Also see
•
Material variant C2 (Noridur) [⇨ 27]
• Material variant C2 (Noridur) [⇨ 27]
