KSB KWP User Manual

Pump size
Description
Pump casing Suction wear plate Discharge cover Shaft Impeller Rolling element bearing Bearing bracket Bearing bracket lantern Stuffing box housing Gland follower Stuffing box ring Lantern ring Gland packing Casing wear ring Thrower Shaft protecting sleeve Impeller screw
Part No.
101 135.01 163 210 230 320/
322
330 344 451.01 452.01 454.01 458.01 461 502.01 507 524.01 906
65-200 3 3 2 1 3 1 1 2 1 1 1 1 1 - 1 1 1
65-201 3 3 2 1 34 1 1 2 1 1 1 1 1 - 1 1 1
80-250 4 4 1 1 4 1 1 1 1 1 1 1 1 - 1 1 1
80-251 4 4 1 1 35 1 1 1 1 1 1 1 1 - 1 1 1
Bearing bracket P04ax
40-315 5 5 3 2 5 2 2 3 2 2 2 2 2 - 2 2 2
50-400 6 6 4 2 6 2 2 4 2 2 2 2 2 - 2 2 2
65-315 7 7 3 2 7 2 2 3 2 2 2 2 2 - 2 2 2
65-313 7 30 3 2 36 2 2 3 2 2 2 2 2 - 2 2 2
65-400 8 8 4 2 8 2 2 4 2 2 2 2 2 - 2 2 2
80-315 9 9 3 2 9 2 2 3 2 2 2 2 2 - 2 2 2
80-311 9 9 3 2 37 2 2 3 2 2 2 2 2 - 2 2 2
100-250 10 10 5 2 10 2 2 1 2 2 2 2 2 - 2 2 2
100-251 10 10 5 2 38 2 2 1 2 2 2 2 2 - 2 2 2
100-253 10 31 5 2 39 2 2 1 2 2 2 2 2 - 2 2 2
100-315 11 11 3 2 11 2 2 3 2 2 2 2 2 - 2 2 2
Bearing bracket P05ax
80-400 12 12 6 3 12 3 3 5 3 3 3 3 3 - 3 3 3
80-403 12 32 6 3 40 3 3 5 3 3 3 3 3 - 3 3 3
100-400 13 13 6 3 13 3 3 5 3 3 3 3 3 - 3 3 3
100-403 13 33 6 3 41 3 3 5 3 3 3 3 3 - 3 3 3
150-315 16 16 7 3 16 3 3 6 3 3 3 3 3 - 3 3 3
150-311 16 16 7 3 42 3 3 6 3 3 3 3 3 - 3 3 3
150-400 17 17 6 3 17 3 3 5 3 3 3 3 3 - 3 3 3
200-320 18 18 7 3 18 3 3 6 3 3 3 3 3 - 3 3 3
Bearing bracket P06x
80-500 19 19 8 4 19 4 4 7 4 4 4 4 4 - 4 4 4
125-500 20 20 9 4 20 4 4 7 4 4 4 4 4 - 4 4 4
125-503 20 34 9 4 43 4 4 7 4 4 4 4 4 - 4 4 4
200-400 21 21 10 4 21 4 4 5 4 4 4 4 4 - 4 4 4
200-403 21 35 10 4 44 4 4 5 4 4 4 4 4 - 4 4 4
250-315 22 - 11 4 22 4 4 6 4 4 4 4 4 33 4 4 4
Bearing bracket P08sx
200-500 23 22 12 4 23 5 5 8 5 5 5 5 5 - 5 5 5
200-501 33 36 12 4 45 5 5 8 5 5 5 5 5 - 5 5 5
200-503 23 37 12 4 46 5 5 8 5 5 5 5 5 - 5 5 5
250-400 24 23 13 4 24 5 5 9 5 5 5 5 5 - 5 5 5
250-403 24 38 13 4 47 5 5 9 5 5 5 5 5 - 5 5 5
250-500 25 24 12 4 25 5 5 8 5 5 5 5 5 - 5 5 5
250-503 25 39 12 4 48 5 5 8 5 5 5 5 5 - 5 5 5
250-505 25 40 12 4 49 5 5 8 5 5 5 5 5 - 5 5 5
250-630 26 25 14 4 26 5 5 9 5 5 5 5 5 - 5 5 5
250-634 26 41 14 4 50 5 5 9 5 5 5 5 5 - 5 5 5
7 Servicing/Maintenance
66 of 78
