KSB Omega Series User Manual

Omega
53
Part no. Description Part no. Description Part no. Description
102 Volute casing 452 Gland cover 561 Grooved pin
105.01 Lower casing half 455 Gland packing 580 Cap
105.02 Upper casing half 457 Stuffing box insert 901 Hex. head bolt
211 Pump shaft 458 Neck ring 902 Stud
234 Impeller 461 Lantern ring 903 Sc rewed plug
321 Deep--groove ball bearing 502 Casing wear ring 904 Grub screw
350 Bearing housing 503 Impeller wear ring 920 Nut
360 Bearing cover 520 Sleeve 932 Circlip
411 V--ring 524 Shaft protecting s leeve 940 Key
412 O-ring 550 Washer 950 Cup spring
421 Radial shaft seal ring
441 Housing for shaft seal

KSB Omega Series Specifications

General

Type	Centrifugal Pump
Series	Omega
Operating Pressure	Up to 16 bar
Application	Water supply, irrigation
Impeller Type	Closed impeller
Casing Material	Cast iron, Stainless steel
Material	Cast iron, Bronze, Stainless steel
