Omega
55
Part no. Description Part no. Description Part no. Description
102 Volute casing 421 Radial shaft seal ring 901 Hex. head bolt
105.01 Lower casing half 433 Mechanical seal 903 Screwed plug
105.02 Upper casing half 441 Housing for shaft seal 920 Nut
211 Pump shaft 457.02 Stuffing box insert 932 Circlip
234 Impeller 503 Impeller wear ring 940 Key
321 Deep--groove ball bearing 520 Sleeve 950 Cup spring
350 Bearing housing 524.01 Shaft protecting sleeve
360 Bearing cover 525.02 Spacer sleeve
411 V--ring 550 Washer
412 O-ring 561 Grooved pin
580 Cap

KSB Omega Series Specifications

General

Type	Centrifugal Pump
Series	Omega
Operating Pressure	Up to 16 bar
Application	Water supply, irrigation
Impeller Type	Closed impeller
Casing Material	Cast iron, Stainless steel
Material	Cast iron, Bronze, Stainless steel
