CAUTION
Contact of O-ring with graphite or similar material
Fluid could escape!
▷ Do not coat O-ring with graphite or similar material.
▷ Use animal fats or lubricants based on silicone or PTFE.
▪ Assembly adhesives
– For gaskets, avoid the use of assembly adhesives, if possible.
–
If assembly adhesives are required, use a commercially available contact
adhesive (e.g. "Pattex").
– Only apply adhesive at selected points and in thin layers.
– Never use quick-setting adhesives (cyanoacrylate adhesives).
– Coat the locating surfaces of the individual components and screwed
connections with graphite or similar before reassembly.
For reassembly, tighten all screws and bolts as specified in this manual.
7.5.2 Fitting the bearings
✓ The individual parts have been placed in a clean and level assembly area.
✓ All dismantled parts have been cleaned and checked for wear.
✓ Any damaged or worn parts have been replaced by original spare parts.
✓ The sealing surfaces have been cleaned.
WARNING
Hot surfaces due to heating of components for assembly/dismantling
Risk of burns!
▷ Wear heat-resistant protective gloves.
▷ Remove flammable substances from the danger zone.
1. Heat up angular contact ball bearing 320.02 and the inner ring of cylindrical
rolling element bearing 322.01 to approximately 80 ℃ in an oil bath or by
means of an induction heater.
2. Guide angular contact ball bearing 320.02 onto shaft 210 as far as it will go.
3.
Slide the inner ring of cylindrical roller bearing 322.01 onto shaft 210 as far as it
will go.
4. For bearing brackets B03 and B05 make sure that disc 550 is positioned
correctly.
NOTE
Angular contact ball bearings must be installed in back-to-back arrangement.
Angular contact ball bearings installed in pairs must always be from the same
manufacturer.
5. Use a C-spanner to tighten slotted round nut 920.21 (right-hand thread)
without lock washer 931.01.
6. Let angular contact ball bearing 320.01 cool down to approximately 5 °C above
ambient temperature.
7.
Re-tighten slotted round nut 920.21, then unscrew it again.
8. Apply a few spots of a suitable lubricant (e.g. Molykote) to the contact faces of
lock washer 931.01 and slotted round nut 920.21.
9. Fit lock washer 931.01.
10. Tighten slotted round nut 920.21.
11. Bend back lock washer 931.01.
12. If provided, slide oil thrower 508.01 on shaft 210.
Tightening torques
