KSB RPH - Enclosure;Insulation

Size
Suction nozzle Discharge nozzle
Forces
[N]
Moments
[Nm]
Forces
[N]
Moments
[Nm]
F
x
F
y
F
z
F
res
M
x
M
y
M
z
M
res
F
x
F
y
F
z
F
res
M
x
M
y
M
z
M
res
150-630 9780 7560 6220 13840 7060 3520 5160 9420 4980 4100 6220 8960 4600 2360 3520 6260
200-280 13340 10680 8900 19260 10040 4880 7600 13500 7560 6220 9780 13840 7060 3520 5160 9420
200-360 13340 10680 8900 19260 10040 4880 7600 13500 7560 6220 9780 13840 7060 3520 5160 9420
200-401 13340 10680 8900 19260 10040 4880 7600 13500 7560 6220 9780 13840 7060 3520 5160 9420
200-450 13340 10680 8900 19260 10040 4880 7600 13500 7560 6220 9780 13840 7060 3520 5160 9420
200-501 13340 10680 8900 19260 10040 4880 7600 13500 7560 6220 9780 13840 7060 3520 5160 9420
200-670 13340 10680 8900 19260 10040 4880 7600 13500 7560 6220 9780 13840 7060 3520 5160 9420
250-401 16000 13340 10680 23400 12200 5960 9220 16420 10680 8900 13340 19260 10040 4880 7600 13500
250-501 16000 13340 10680 23400 12200 5960 9220 16420 10680 8900 13340 19260 10040 4880 7600 13500
250-630 16000 13340 10680 23400 12200 5960 9220 16420 10680 8900 13340 19260 10040 4880 7600 13500
250-710 16000 13340 10680 23400 12200 5960 9220 16420 10680 8900 13340 19260 10040 4880 7600 13500
300-400 17800 14240 11560 25560 12740 6240 9500 17080 13340 10680 16000 23400 12200 5960 9220 16420
300-500 17800 14240 11560 25560 12740 6240 9500 17080 13340 10680 16000 23400 12200 5960 9220 16420
300-630 17800 14240 11560 25560 12740 6240 9500 17080 13340 10680 16000 23400 12200 5960 9220 16420
350-400 17800 14240 11560 25560 12740 6240 9500 17080 14240 11560 17800 25560 12740 6240 9500 17080
350-500 17800 14240 11560 25560 12740 6240 9500 17080 14240 11560 17800 25560 12740 6240 9500 17080
350-650 20460 16900 13340 29700 14640 7340 10840 19640 14240 11560 17800 25560 12740 6240 9500 17080
350-710 20460 16900 13340 29700 14640 7340 10840 19640 14240 11560 17800 25560 12740 6240 9500 17080
400-504 20460 16900 13340 29700 14640 7340 10840 19640 16900 13340 20460 29700 14640 7340 10840 19640
400-506 20460 16900 13340 29700 14640 7340 10840 19640 16900 13340 20460 29700 14640 7340 10840 19640
400-710 20460 16900 13340 29700 14640 7340 10840 19640 16900 13340 20460 29700 14640 7340 10840 19640
5.4.3 Auxiliary connections
DANGER
Risk of potentially explosive atmosphere by mixing of incompatible fluids in the
auxiliary piping
Risk of burns!
Explosion hazard!
▷ Make sure that the barrier fluid and quench liquid are compatible with the
fluid pumped.
WARNING
Failure to use or incorrect use of auxiliary connections (e.g. barrier fluid, flushing
liquid, etc.)
Risk of injury from escaping fluid!
Risk of burns!
Malfunction of the pump!
▷ Refer to the general arrangement drawing, the piping layout and pump
markings (if any) for the quantity, dimensions and locations of auxiliary
connections.
▷ Use the auxiliary connections provided.
5.5 Enclosure/insulation
DANGER
Risk of potentially explosive atmosphere due to insufficient venting
Explosion hazard!
▷ Make sure the space between the casing cover/discharge cover and the bearing
cover is sufficiently vented.
▷ Never close or cover the perforation of the bearing bracket guards (e.g. by
insulation).
5 Installation at Site
24 of 76
RPH
