7.7 Spare parts stock
7.7.1 Ordering spare parts
Always quote the following data when ordering replacement or spare parts:
▪ Type series
▪ Size
▪ KSB order number
▪ Material variant
▪ Year of construction
Refer to the name plate for all data. (⇨ Section 4.3 Page 16)
Also specify the following data:
▪ Description
▪ Part No.
▪ Quantity of spare parts
▪ Shipping address
▪ Mode of dispatch (freight, mail, express freight, air freight)
Refer to the general assembly drawing for part numbers and descriptions.
(⇨ Section
9.1 Page 62)
7.7.2 Recommended spare parts stock for 2 years' operation to DIN 24296
Table 21: Quantity of spare parts for recommended spare parts stock
Part No. Description Number of pumps (including stand-by pumps)
2 3 4 5 6 and 7 8 and 9 10 and
more
210 Shaft 1 1 1 2 2 2 20 %
230 Impeller 1 1 1 2 2 2 20 %
23-2 Auxiliary impeller 1 1 1 2 2 2 20 %
320.02 Angular contact ball bearing
(set)
1 1 2 2 2 3 25 %
322.01 Cylindrical roller bearing 1 1 2 2 2 3 25 %
330 Bearing bracket - - - - - 1 2
502.01/.02
22)
Casing wear ring 2 2 2 3 3 4 50 %
503.01/.02
22)
Impeller wear ring 2 2 2 3 3 4 50 %
542.02 Throttling bush 1 1 2 2 2 3 30 %
- Sealing elements 4 6 8 8 9 10 100 %
433 Mechanical seal, complete 1 1 2 2 2 3 25 %
22)
If any
