60 Hz Submersible Borehole Pumps
96
Typical Tender UPA 100C
No. Qty Item
Unit price Amount
p
Submersible borehole pump(s) type UPA 100C for well diameters of
100 mm (4 inches) and above.
Marke: KSB
Pump + motor: UPA 100C -- / +
Multistage centrifugal pump for vertical / angled / horizontal
1)
installation.
Components of stainless steel with a minimum wall thickness of 1 mm and vanes
welded at 6 points. Integrated check valve. Generously dimensioned plain
bearing lubricated by the fluid handled. Discharge nozzle with threaded end.
Submersible canned motor for three-phase current, with self--aligning thrust
bearing, expansion diaphragm for pressure equalization and cable kit
1.5 / 2.5
1)
m power supply cable.
Max. permissible submergence below maximum water level: 350 m.
Fluid handled: clean or slightly contaminated water with a permissible
sandcontentofupto50g/m
3
.
Suction and discharge casing CrNi steel...............
Diffusers CrNi steel.................................
Impellers CrNi steel.................................
Shaft (pump) CrNi steel.............................
Bearing (pump) Rubber...........................
Motor (shaft and housing) CrNi steel..................
Capacity Q =
m
3
/h / l/s...................
Head H = m......................
Temperature (fluid handled) t = °C...
Rated power (motor) P
N
= kW / hp.........
Speed / Frequency n ≈ rpm/f= Hz..........
Voltage / Starting U = V/ direct............
Pump end Rp 1
1
/
2
’’ (DN 40) / 2’’ (DN 50)
1)
..................
Outside diameter D
max
= mm............
Pump set length / weight L
A
≈ mm/G
A
≈_____kg.....
Adapter from G to DN .
Pair of supporting and installation clamps
for risers Rp 1
1
/
2
’’ (DN 40) / R2’’ (DN 50)
1)
.
Power supply cable x mm
2
, separate / connected
1)
,
length m
Cable connector, separable / non-separable
1)
, with sealing compound,motor
supply cable not connected and sealed / connected and sealed
1)
at the factory.
Cable tie
UPA CONTROL box for 3~ / 400 V with thermal overcurrent relay with phase
failure protection, temperature-compensated, insulating enclosure, with 3 elec-
trodes and integrated ”Dry running protection” / ”Water level control” selector
switch.
Motor contactor for 1~ / 230 V with ON / OFF switch for automatic operation,
insulating enclosure.
Dry running protection equipment:
-- f o r semi-automatic operation with 2
1)
-- f o r fully automatic operation with 3
1)
control current lines with a length of m each.
Lightning protection with earthing terminal for 3~ 400 V.
Sum total
1)
Delete as applicable
