KSB S 100D - Typical Tenders: 4 to 14 Inches

Submersible Borehole Pumps60 Hz
95
Typical Tender for S 100D
No. Quan-
i
Item Unit price
E
Amount
E
Q
tity
p
Euro Euro
Submersible borehole pump(s) type S 100D
for well diameters of 100 mm (4 inches) and above
Make: KSB
Pump + motor: S 100D -- / + kW...... ..... ..............
Multistage centrifugal pump for vertical / angled / horizontal
1)
installation. Inte-
grated, check valve with double-guided valve disc. Plain bearing lubricated by
the fluid handled and protected against ingress of sand. Discharge nozzle with
threaded end.
Submersible canned motor for three-phase current, with self--aligning thrust
bearing, expansion diaphragm for pressure equalization and cable kit
1.5 / 2.5
1)
m power supply cable.
Max. permissible submergence below maximum water level: 350 m.
Fluid handled: clean or slightly contaminated water with a permissible sand
content of up to 50 g/m
3
!
Outer pump casing, suction casing and
check valve housing CrNi steel........................
Stage casing (diffuser) glass fibre reinforced NORYL.....................
Impellers glass fibre reinforced NORYL.................................
Shaft (pump) Chrome steel.............................
Bearing (pump) Rubber...........................
Motor (shaft and housing) CrNi steel..................
Capacity Q =
m
3
/h / l/s................
Head H =
m...................
Temperature (fluid handled) t =
o
C
Rated power (motor) P
N=
kW / hp......
Speed / Frequency n
¶ rpm/f= Hz.......
Voltage / Starting U =
V / d.o.l..........
Pump end G 1
1
/
4
’’ (DN 32) / 2’’ (DN 50)
1)
...............
Outside diameter D
max
= mm.........
Pump set length / weight L
A
¶ mm / G
A
¶ kg..
Adapter from G 1
1
/
4
’’ to R 1
1
/
2
’’ .
Adapter from threaded end G
to flanged end DN .
Pair of supporting and installation clamps for risers
R1
1
/
4
’’ (DN 32) / R2’’ (DN 50)
1)
.
Cooling shroud with suction strainer and pedestals for horizontal
installation.
Power supply cable x mm
2
, separate/connected
1)
, length m.
Cable connector, separable / non-separable
1)
, with sealing compound,
motor supply cable not connected and sealed/connected and sealed
1)
at the factory.
Cable tie
UPA CONTROL box for 3 µ/ 400 V with thermal overcurrent relay with phase
failure protection, temperature-compensated, insulating enclosure, with
3 electrodes and integrated ”Dry running protection” / ”Water level control”
selector switch.
Motor contactor for 1 µ/ 230 V with ON/OFF switch for automatic operation,
insulating enclosure.
Dry running protection equipment:
-- f o r semi- automatic operation with 2
1)
-- f o r fully automatic operation with 3
1)
control current lines with a length of m each.
Lightning protection with earthing terminal for 3
µ 400 V.
Automatic control unit Controlmatic E / Cervomatic EDP
1)
.
Sum total
1)
Delete as applicable
