1. Fit all connecting lines and check that they function properly.
5.12 Fitting the protective equipment
WARNING
Failure to re-install or re-activate protective devices
Risk of injury from moving parts or escaping fluid!
▷ As soon as the work is completed, re-install and/or re-activate any safety-
relevant and protective devices.
WARNING
Distributor casing and bearing housing take on the same temperature as the fluid
handled.
Risk of burns!
▷ Insulate the distributor casing.
▷ Fit protective equipment.
CAUTION
Heat build-up in the bearing housing
Damage to the bearing!
▷ Never insulate the bearing housing and bearing cover.
1. Fit all protective equipment, such as guards, monitoring devices, etc.
5.13 Installation checklist
Table 11: Checklist: Installation
Steps Work required Done: ✔
1 The supplied pump (set) and accessories have been checked for
completeness and transport damage.
2 The condition and dimensions of the foundation have been
verified against the general arrangement drawing.
3 The sole plate has been roughly aligned by means of levelling
screws/shims.
4 The foundation bolts have been inserted into the sole plate.
5 The can has been roughly aligned.
6 The foundation bolts have been set in concrete.
7 The concrete has set.
8 The pump set components have been aligned.
9 The foundation bolts have been tightened.
10 The sole plate has been grouted with concrete.
11 The drive has been mounted.
5 Installation at Site
WKTR
37 of 78
