KSB WKTR - 9.4 Related Documents & 9.5 Pump Signage

Number
of
stages
Column
pipe up
to
Standar
d
column
pipe
Size
40
Sizes
50 and 65
Sizes
80 and 100
Size
125
Size
150
Empty
weight
[kg]
Volume
[l]
Empty
weight
[kg]
Volume
[l]
Empty
weight
[kg]
Volume
[l]
Empty
weight
[kg]
Volume
[l]
Empty
weight
[kg]
Volume
[l]
07 900 396 32 589 48 958 74 1190 124 1605 175
08 300 2 x 900 401 34 594 51 968 78 1190 133 1620 185
09 600 406 36 599 54 978 82 1205 142 1635 195
10 900 426 38 629 57 1008 86 1255 151 1705 205
11 300 3 x 900 431 40 634 60 1018 90 1270 160 1720 215
12 600 436 42 639 63 1028 94 1295 169 1735 225
13 900 441 44 644 66 1038 98 1310 178 1750 235
9.4 Related Documents
For further information refer to the following sub-sections.
Section Contents
Section 9.4.1 Pump set
Section 9.4.2 Pump
Section 9.4.3 Connecting coupling
Section 9.4.4 Drive
Section 9.4.5 Minimum flow system
Section 9.4.6 Valves and equipment
Section 9.4.7 Measuring instruments
Section 9.4.9 Protective equipment
9.5 Pump signage
Observe the following signs at the pump (set).
NOTE
Always observe all signs at the pump (set).
Keep signs, plates and labels in a perfectly legible condition at all times.
Immediately replace any damaged or illegible signs, plates or labels by new ones.
1
2
3
! ! ! !
Betriebshandbuch beachten.
Observe the instruction manual.
Observer le manuel d‘instructions.
Obsérvense el manual de
instrucciones.
Observar instrucões do Manual de
Servico.
Osservare il manuale di istruzioni.
Bedrijfshandleiding opvolgen.
Vær opmærksom på driftshånbag.
Προσεζτε το βιβλιο με τιξ οδηγεξ.
Observera instruktionshandboken.
Käsikirjan ohjeita on noudatettava.
Dodržuj provozni předpis
Mat.No.: 01040645 ZN 3827 - 21 M
DE
EN
FI
SV
EL
DK
NL
IT
PT
ES
FR
CS
Ident.-No. 01 068 246 ZN 3823 - 215
II 2 G c Tx
>176 °F
> 80 °C
> 150
> 150
> 150
> 150
Ident-Nr. xxxxxx ZN xxxxxx
! ! ! ! !
Type:
Sr. No.:
Item No.:
Q m
3
/h H m n rpm
Rating kW Hy. Test Pr. bar
MAW Pr. bar MAW Temp. °C
Brg DE Brg. NDE
A 52 x 74
4
5
6
WEIGHT:
View from the suction nozzle View from the discharge nozzle
9 Related Documents
WKTR
73 of 78
