Weight: p u m p section
Table 24: Weights in kg
Number of
stages
Size
40
Size
50
Size
65
Size
80
Size
100
Size
120
Size
150
01 41 52 62 79 90 123 207
02 50 63 76 103 115 161 278
03 59 74 90 127 140 199 349
04 68 85 104 151 165 237 420
05 77 96 118 175 190 275 491
06 86 107 132 199 215 313 562
07 95 118 146 223 240 351 633
08 104 129 160 247 265 384 704
09 113 140 174 271 290 422 --
10 122 151 188 295 315 460 --
11 131 162 202 319 340 -- --
12 140 173 216 343 -- -- --
13 149 184 230 -- -- -- --
14 158 495 244 -- -- -- --
15 167 206 -- -- -- -- --
16 176 -- -- -- -- -- --
Weight: i n t e r mediate shaft w i t h conical cou p l i n g
Table 25: Weight and dimensions
Sizes
40 to 100
Size 125 Size 150
Shaft length [mm] 898 898 898
Shaft diameter [mm] 35 45 60
Shaft weight [kg] 7 11.4 20
Weight: d r i v e shaft relate d t o the length o f t h e upper column p i pe
Table 26: Weights in kg
Length of the
column pipe
[mm]
Size
40
Sizes
50 and 65
Sizes
80 and 100
Size
125
Size
150
without 5 5.2 7.8 14.8 16.3
300 7.25 7.45 11.5 20 23.6
600 9.5 9.7 15.2 25.2 31
900 11.75 12 19 30.4 38.4
Weight: a s s e m bly motor sto o l , coupling, bea r i n g housing, driv e
sh
aft, dist r i b u tor casing an d c o lumn pipe
Table 27: Weight and volume
Number
of
stages
Column
pipe up
to
Standar
d
column
pipe
Size
40
Sizes
50 and 65
Sizes
80 and 100
Size
125
Size
150
Empty
weight
[kg]
Volume
[l]
Empty
weight
[kg]
Volume
[l]
Empty
weight
[kg]
Volume
[l]
Empty
weight
[kg]
Volume
[l]
Empty
weight
[kg]
Volume
[l]
01 -- -- 341 20 524 30 868 50 1030 70 1425 115
02 300 356 22 544 33 888 54 1060 79 1475 135
03 600 361 24 549 36 898 58 1075 88 1490 135
04 900 366 26 554 39 908 62 1090 97 1505 145
05 300 900 371 28 579 42 918 66 1105 106 1590 165
06 600 391 30 584 45 948 70 1160 115 1590 165
