Part No. Description Part No. Description
145 Adapter 562.1/.2/.3 Parallel pin
151 Can 638 Constant-level oiler
165 Cooling chamber cover 641 Oil level pipe
171.1/.2 Diffuser 646 Oil tube
211 Pump shaft 680.1 Guard
213 Drive shaft 681 Coupling guard
230 Impeller 711.1 Steigrohr
231 Suction impeller 851 Conical coupling
320 Wälzlager 893 Sole plate
341 Drive lantern/motor stool 901.1/.2/.5/.6 Hexagon head bolt
350 Bearing housing 902.12/.13/.14 Stud
360 Bearing cover 903 Screw plug
400.1/.2/.4/.5/.6/.7 Gasket 904.1/.2/.3/.5 Grub screw
412.1/.2/.3 O-ring 905 Tie bolt
433 Mechanical seal 913 Vent plug
451 Stuffing box housing 914 Hexagon socket head cap screw
501 Ring 920.2/.5/.6/.11/.12/.
13/.14
Nut
502.1/.2 Casing wear ring 924 Adjusting nut
503 Impeller wear ring 931 Lockwasher
521 Stage sleeve 940.1/.2/.3/.4 Key
9.3 Weights of pump assemblies
Weight: c a n
Table 23: Weight and volume
Size 40 Sizes 50 and 65 Sizes 80, 100 and 125 Size 150
Length of
the can
[mm]
Empty
weight
[kg]
Volume
[l]
Empty
weight
[kg]
Volume
[l]
Empty
weight
[kg]
Volume
[l]
Empty
weight
[kg]
Volume
[l]
600 175 40 245 52 501 112 -- --
650 175 40 245 52 501 112 -- --
900 203 61 277 80 552 159 872.5 246
1200 232 82 310 108.5 614 215 969 335
1500 260 103.5 342 135.5 675 271 1066 424
1800 289 124.5 375 163.5 736.5 327 1162 513
2100 317 146 407 191.5 798 383 1259 602
2400 346 167 440 219.5 859.5 439 1355.5 691
2700 374 188 472 247.5 921 495 1452 780
3000 403 209.5 505 275.5 982 551 1548.5 869
3300 431 230.5 537 303.5 1044 607 1645 958
3600 460 252 570 331.5 1105 663 1742 1047
3900 488 273 602 359.5 1167 719 1838 1136
4200 517 294 635 387.5 1228 775 1935 1225
4500 545 315 667 415.5 1290 831 2031.5 1314
4800 574 336.5 700 443.5 1351 887 2128 1403
5100 602 357.5 732 471.5 1412.5 943 2225 1492
5400 630.5 379 765 499.5 1474 999 2321 1581
9 Related Documents
