KTM 1090 Adventure R User Manual

TABLE OF CONTENTS
4
6.5 Switches on the right side of the
handlebar........................................ 36
6.5.1 Emergency OFF switch ................. 36
6.5.2 Electric starter button .................. 36
6.6 Ignition/steering lock........................ 37
6.7 Immobilizer..................................... 38
6.8 Locking the steering......................... 39
6.9 Unlocking the steering...................... 40
6.10 Opening the filler cap....................... 40
6.11 Closing the filler cap ........................ 42
6.12 Fuel cocks....................................... 44
6.13 Opening the storage compartment ..... 44
6.14 Closing the storage compartment....... 45
6.15 Seat lock......................................... 45
6.16 Grab handles ................................... 46
6.17 Luggage rack plate........................... 46
6.18 Case holders.................................... 47
6.19 Passenger footrest............................ 48
6.20 Shift lever ....................................... 48
6.21 Foot brake lever ............................... 49
6.22 Side stand....................................... 50
7 COMBINATION INSTRUMENT ..................... 51
7.1 Overview ......................................... 51
7.2 Activation and test ........................... 51
7.3 Matrix display.................................. 53
7.4 Segment display .............................. 53
7.5 Fuel level display ............................. 54
7.6 Indicator lamps................................ 55
7.7 Message on the matrix display........... 57
7.8 Shift warning light ........................... 59
7.9 service display ................................. 60
7.10 Matrix display menu......................... 60
7.10.1 "Favorites"................................... 60
7.10.2 "Trip 1"....................................... 61
7.10.3 "Trip 2"....................................... 62
7.10.4 "General Info" .............................. 63
7.10.5 "Set Favorites" ............................. 63
7.10.6 "Settings".................................... 64
7.10.7 "Warning".................................... 64
7.10.8 "Heating" (optional)...................... 65
7.10.9 "MTC/ABS".................................. 65
7.10.10 "Drive Mod" ................................. 66
7.10.11 menu overview............................. 68
7.10.12 "Language".................................. 69
7.10.13 "Distance" ................................... 70
7.10.14 "Temp" ....................................... 70
7.10.15 "Pressure" ................................... 71
7.10.16 "Fuel Cons" ................................. 71
7.10.17 "Clock/Date" ................................ 72
7.10.18 "Shift Light" ................................ 72
7.10.19 "Heat Grip".................................. 73

KTM 1090 Adventure R Specifications

General

Displacement	1050 cc
Torque	109 Nm
Transmission	6-speed
Fuel Capacity	23 liters
Seat Height	890 mm
Dry Weight	207 kg
Front Suspension	WP USD Ø 48 mm
Bore x Stroke	103 mm x 63 mm
Compression Ratio	12.5:1
Starter	Electric starter
Fuel System	Electronic fuel injection
Front Wheel	2.50 x 21"
Rear Wheel	4.50 x 18"
Front Tire	90/90-21
Rear Tire	150/70-18
Ground Clearance	250 mm
Engine Type	V-Twin, 4-stroke, DOHC
Power	125 hp (92 kW)
Rear Suspension	WP shock absorber
Front Brake	2 x 320 mm discs, 4-piston radial fixed calipers
Rear Brake	Brembo 2-piston caliper, 267 mm disc
ABS	Bosch 9M+ two-channel ABS (disengageable)
Frame	Chromium-Molybdenum steel trellis frame, powder-coated
