KTM 1090 Adventure R User Manual

TABLE OF CONTENTS
5
7.10.20 "DRL" ......................................... 74
8 ERGONOMICS ............................................ 76
8.1 Handlebar position........................... 76
8.2 Adjusting the handlebar position .... 76
8.3 Adjusting the wind shield ................. 78
8.4 Adjusting basic position of clutch
lever ............................................... 80
8.5 Adjusting the basic position of the
hand brake lever .............................. 81
8.6 Rider footrests ................................. 81
8.7 Adjusting the footrests .................. 82
8.8 Checking the basic position of the
shift lever........................................ 85
8.9 Adjusting the basic position of the
shift lever .................................... 86
8.10 Adjusting the basic position of the
foot brake lever ............................ 88
9 PREPARING FOR USE................................. 89
9.1 Advice on preparing for first use ........ 89
9.2 Running in the engine ...................... 91
9.3 Loading the vehicle.......................... 91
10 RIDING INSTRUCTIONS.............................. 94
10.1 Checks and maintenance measures
when preparing for use ..................... 94
10.2 Starting the vehicle .......................... 95
10.3 Starting off...................................... 97
10.4 Shifting, riding ................................ 98
10.5 Applying the brakes........................ 103
10.6 Stopping, parking........................... 106
10.7 Transporting .................................. 108
10.8 Refueling ...................................... 109
11 SERVICE SCHEDULE ................................ 112
11.1 Additional information.................... 112
11.2 Required work ............................... 112
11.3 Recommended work ....................... 115
12 SUSPENSION SETTING............................. 116
12.1 Fork/shock absorber ....................... 116
12.2 Adjusting the compression
damping of the fork........................ 116
12.3 Adjusting the rebound damping of
the fork......................................... 118
12.4 Adjusting the spring pretension of
the fork......................................... 119

KTM 1090 Adventure R Specifications

General

Displacement	1050 cc
Torque	109 Nm
Transmission	6-speed
Fuel Capacity	23 liters
Seat Height	890 mm
Dry Weight	207 kg
Front Suspension	WP USD Ø 48 mm
Bore x Stroke	103 mm x 63 mm
Compression Ratio	12.5:1
Starter	Electric starter
Fuel System	Electronic fuel injection
Front Wheel	2.50 x 21"
Rear Wheel	4.50 x 18"
Front Tire	90/90-21
Rear Tire	150/70-18
Ground Clearance	250 mm
Engine Type	V-Twin, 4-stroke, DOHC
Power	125 hp (92 kW)
Rear Suspension	WP shock absorber
Front Brake	2 x 320 mm discs, 4-piston radial fixed calipers
Rear Brake	Brembo 2-piston caliper, 267 mm disc
ABS	Bosch 9M+ two-channel ABS (disengageable)
Frame	Chromium-Molybdenum steel trellis frame, powder-coated
