KTM 125 Duke Setup Instructions

1 MEANS OF REPRESENTATION
2
1.1 Symbols used
The meaning of specific symbols is described below.
Indicates an expected reaction (e.g. of a work step or a function).
Indicates an unexpected reaction (e.g. of a work step or a function).
Indicates a page reference (more information is provided on the specified page).
Indicates information with more details or tips.
Indicates the result of a testing step.
Indicates a voltage measurement.
Indicates a current measurement.
Indicates a resistance measurement.
Indicates the end of an activity including potential rework.
1.2 Formats used
The typographical formats used in this document are explained below.
Proprietary name Indicates a proprietary name.
Name
®
Indicates a protected name.
Brand™ Indicates a brand available on the open market.
Underlined terms Refer to technical details of the vehicle or indicate technical terms, which
are explained in the glossary.

KTM 125 Duke Specifications

General

Displacement	124.7 cc
Max Power	14.5 hp @ 9, 250 rpm
Max Torque	12 Nm @ 8, 000 rpm
Transmission	6-speed
Front Suspension	WP APEX 43
Rear Suspension	WP APEX Monoshock
Fuel Tank Capacity	13.4 liters
Seat Height	830 mm
Bore x Stroke	58 mm x 47.2 mm
Compression Ratio	12.8:1
Ground Clearance	175 mm
Wheelbase	1, 357 mm
Front Tyre	110/70 R17
Rear Tyre	150/60 R17
Fuel System	Electronic Fuel Injection (EFI)
Rear Brake	230 mm disc
Frame	Steel trellis frame, powder-coated
Engine Type	Single Cylinder, 4 Stroke, Liquid Cooled, DOHC
