13 SERVICE WORK ON THE CHASSIS 101
Info
Chain wear is not always even, so you should check the setting at different chain
positions.
Tighten screw
1
.
Guideline
Screw, eccentric M16 50 Nm
(36.9 lbf ft)
Finishing work
Remove the rear of the motorcycle from the lifting gear. ( p. 89)
13.16 Checking the chain, rear sprocket, engine sprocket, and chain guide
100132-10
Check the rear sprocket and engine sprocket for wear.
» If the rear sprocket and engine sprocket are worn:
Change the drivetrain kit. x
Info
The engine sprocket, rear sprocket, and chain should always be replaced
together.
