KTM 1290 Super Duke R User Manual

12 SUSPENSION SETTING 83
Guideline
Rebound damping
Comfort 17 clicks
Standard 12 clicks
Sport 7 clicks
Full payload 7 clicks
Info
Turn clockwise to increase damping; turn counterclockwise to reduce damping.
12.4 Compression damping of the shock absorber
500313-01
The compression damping of the shock absorber is divided into two ranges: high-speed and
low-speed.
High-speed and low-speed refer to the compression speed of the rear wheel suspension and
not to the vehicle speed.
The high-speed setting, for example, has an effect on the landing after a jump: the rear
wheel suspension compresses more quickly.
The low-speed setting, for example, has an effect when riding over long ground swells: the
rear wheel suspension compresses more slowly.
These two ranges can be adjusted separately, although the transition between high-speed
and low-speed is gradual. Thus, changes in the high-speed range affect the compression
damping in the low-speed range and vice versa.

KTM 1290 Super Duke R Specifications

General

Displacement	1301 cc
Transmission	6-speed
Seat Height	835 mm
Fuel Tank Capacity	16 liters
Dry Weight	189 kg
Starter	Electric starter
Fuel System	Electronic fuel injection
Traction Control	MTC (Motorcycle Traction Control), lean-angle sensitive
Wheelbase	1482 mm
Front Tire	120/70 ZR 17
Rear Tire	200/55 ZR 17
Engine Type	V-Twin, 4-stroke
Power	180 hp (132 kW) @ 9500 rpm
Torque	140 Nm
Frame	Chromium-Molybdenum steel frame, powder coated
Front Suspension	WP APEX 48
Rear Suspension	WP APEX monoshock
Rear Brake	Brembo two-piston caliper, 240 mm disc
Front Brake	Dual 320 mm discs, Brembo Stylema monobloc calipers
ABS	Bosch 9.1 MP (incl. Cornering-ABS and Supermoto mode)
