ELECTRICAL SYSTEM 103

13.5Changing fuses of individual power consumers

Info

The fuse box containing the fuses of individual power consumers is located under the seat.

– Switch off all power consumers and switch off the engine.

– Remove the seat. ( p. 63)

600604-11

– Open fuse box cover .
