TECHNICAL DATA - CHASSIS 150
Steering head angle 63°
Wheelbase 1,480±15 mm (58.27±0.59 in)
Seat height unloaded 910 mm (35.83 in)
Ground clearance unloaded 290 mm (11.42 in)
Weight without fuel approx. 139.5 kg (307.5 lb.)
Maximum permissible front axle load 150 kg (331 lb.)
Maximum permissible rear axle load 200 kg (441 lb.)
Maximum permissible overall weight 350 kg (772 lb.)
Battery YTZ10S Battery voltage: 12 V
Nominal capacity: 8.6 Ah
maintenance-free
Fuse 58011109130 30 A
Fuse 75011088015 15 A
Fuse 75011088010 10 A
23.1Lighting equipment
Headlight H4 / socket P43t 12 V
60/55 W
Parking light W5W / socket W2.1x9.5d 12 V
5 W
Instrument lights and indicator lamps LED
Turn signal RY10W / socket BAU15s 12 V
10 W
Brake/tail light LED
