15 ELECTRICAL SYSTEM 131
Info
A defective fuse is indicated by a burned-out fuse wire
.
Warning
Fire hazard The electrical system can be overloaded if the wrong fuses are
used.
– Use only fuses with the prescribed amperage. Never bypass or repair fuses.
– Use spare fuses with the correct rating only.
Fuse (75011088005) ( p. 177)
Fuse (75011088010) ( p. 177)
Fuse (75011088015) ( p. 177)
Fuse (75011088030) ( p. 177)
Tip
Replace the spare fuse in the fuse box so that it is available if needed.
– Check that the power consumer is functioning properly.
– Close the fuse box cover.
Finishing work
– Mount the battery cover. ( p. 93)
– Mount the front rider's seat. ( p. 82)
