12 SERVICE WORK ON THE CHASSIS 91
L02167-10
– Push the chain up in the area behind the chain guide.
– Check the chain sliding guard for wear.
» If the chain sliding guard has lost material due to wear to the extent that, in
area
, the drilled hole of screw
is visible from above:
– Change the chain sliding guard.
– Check that the chain sliding guard is firmly seated.
» If the chain sliding guard is loose:
– Tighten the chain sliding guard.
12.14 Removing the battery cover
Preparatory work
– Remove the front rider's seat. ( p. 81)
