23 TECHNICAL DATA 178
23.7 Fork
Fork part number 90801000000
Fork WP Suspension
Fork length 736 mm (28.98 in)
Fork oil 460 ml (15.55 fl. oz.) Fork oil (SAE 4) (48601166S1) ( p. 185)
23.8 Shock absorber
Shock absorber part number 90804010000
Shock absorber WP Suspension
Spring preload
Comfort 3 clicks
Standard 5 clicks
Sport 7 clicks
Full payload 8 clicks
Static sag 15 mm (0.59 in)
Riding sag 45… 50 mm (1.77… 1.97 in)
Fitted length 304 mm (11.97 in)
23.9 Chassis tightening torques
Exhaust clamp - 10 Nm (7.4 lbf ft) –
Screw, chain guard EJOT PT
®
K60x30 4 Nm (3 lbf ft) –
Remaining nuts, chassis M4 3 Nm (2.2 lbf ft) –
Remaining screws, chassis M4 3 Nm (2.2 lbf ft) –
