23 TECHNICAL DATA 179

Screw, EFI control unit M4 3 Nm (2.2 lbf ft) –

Nut, reflector on retaining plate M5 7 Nm (5.2 lbf ft) –

Nut, retaining plate on license plate

holder

M5 4 Nm (3 lbf ft) –

Remaining nuts, chassis M5 5 Nm (3.7 lbf ft) –

Remaining screws, chassis M5 5 Nm (3.7 lbf ft) –

Screw, ABS hose clamp M5 6 Nm (4.4 lbf ft) –

Screw, anti-rotation lock, handlebar stub M5 4 Nm (3 lbf ft) –

Screw, battery compartment M5 4 Nm (3 lbf ft) –

Screw, chain guard M5 7 Nm (5.2 lbf ft) Loctite

204™

Screw, cover in front of battery compart-

ment

M5 4 Nm (3 lbf ft) –

Screw, fuel pump M5 5 Nm (3.7 lbf ft) –

Screw, fuel tank cover M5 5 Nm (3.7 lbf ft) –

Screw, rollover sensor M5 6 Nm (4.4 lbf ft) Loctite

243™

Screw, side stand switch M5 5 Nm (3.7 lbf ft) Loctite

243™

Screw, tail end lower part M5 4 Nm (3 lbf ft) –

Cap bolt, footrest M6 9 Nm (6.6 lbf ft) –

Nut, foot brake lever adjustment M6 10 Nm (7.4 lbf ft) –

Nut, license plate bracket M6 8.5 Nm (6.27 lbf ft) –

Nut, shift rod M6 10 Nm (7.4 lbf ft) –

Nut, shift rod M6LH 10 Nm (7.4 lbf ft) –

Nut, tail light M6 7 Nm (5.2 lbf ft) –

Remaining nuts, chassis M6 10 Nm (7.4 lbf ft) –

Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –

KTM 2015 RC 390 JP User Manual
