22 TECHNICAL DATA
162
Spring rate
Weight of rider: 65 … 75 kg (143 … 165 lb.) 60 N/mm (343 lb/in)
Weight of rider: 75 … 85 kg (165 … 187 lb.) 63 N/mm (360 lb/in)
Weight of rider: 85 … 95 kg (187 … 209 lb.) 66 N/mm (377 lb/in)
Spring length 225 mm (8.86 in)
Gas pressure 10 bar (145 psi)
Static sag 35 mm (1.38 in)
Riding sag 110 mm (4.33 in)
Fitted length 415 mm (16.34 in)
Shock absorber fluid ( p. 165) SAE 2.5
22.10 Chassis tightening torques
Remaining screws, chassis EJOT PT
®
K60x25‑Z 2 Nm (1.5 lbf ft)
Screw, seat fixing EJOT EJOFORM PT
®
K60x23/18 2.5 Nm (1.84 lbf ft)
Screw, emergency OFF switch
(EXC AU)
M4 0.7 Nm (0.52 lbf ft)
Screw, fixed grip M4 5 Nm (3.7 lbf ft)
Loctite
®
243™
Spoke nipple, front wheel M4.5 6 Nm (4.4 lbf ft)
Spoke nipple, rear wheel M4.5 6 Nm (4.4 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, battery terminal M5 2.5 Nm (1.84 lbf ft)
Screw, light switch (All EXC mod-
els)
M5 1 Nm (0.7 lbf ft)
Screw, shock absorber adjusting
ring
M5 5 Nm (3.7 lbf ft)
Screw, turn signal switch (All EXC
models)
M5 1 Nm (0.7 lbf ft)
Nut, cable on starter motor M6 4 Nm (3 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Screw, ball joint of push rod on
foot brake cylinder
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, chain sliding guard M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, front brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, manifold on silent block M6 6 Nm (4.4 lbf ft)
Screw, rear brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, silent block on frame M6 6 Nm (4.4 lbf ft)
Screw, throttle grip M6 5 Nm (3.7 lbf ft)
Nut, foot brake lever M8 15 Nm (11.1 lbf ft)
Nut, foot brake lever stop M8 20 Nm (14.8 lbf ft)
Nut, pull switch (All XC‑W models) M8 0.4 Nm (0.3 lbf ft)
